Carousel pouring machine for glass, plastic and tin packaging "HUGART MACHINES"

Carousel pouring machine for glass, plastic

and tin packaging "HUGART MACHINES"

The HUGART MACHINES rotary filling machine is designed for filling glass, plastic, and metal containers. Thanks to its stable stainless steel construction, high dosing precision, and smoothly adjustable capacity, it performs reliably in medium- and large-scale production facilities. The machine handles both liquid and semi-liquid products, making it a versatile solution for various industries, including food, chemical, and cosmetic sectors.

The model is equipped with safety guards fitted with sensors that stop the machine when opened, ensuring maximum operator protection and compliance with occupational health and safety standards.

Key Advantages

• Precise and repeatable filling
• High capacity – up to 4,000 containers per hour
• Wide range of supported container sizes and types
• Durable stainless steel construction resistant to corrosion and intensive use
• Intuitive operation and easy parameter adjustment

Overall Dimensions

• Length: 1,300 mm
• Width: 1,000 mm
• Height: 1,800 mm

Technical Data

• Filling container height range: 75–160 mm
• Container diameter: 70–120 mm
• Filling volume range: 100–1,000 ml
• Tank capacity: 230 l (with level sensor)
• Product type: liquid and semi-liquid
• Capacity: up to 4,000 pcs/hour (smooth adjustment)
• Machine weight: approx. 400 kg
• Power consumption: approx. 0.5 kW
• Construction material: stainless steel
• Safety guards: with stop sensors
• Year of manufacture: 2005
• Serial number: 619

Application

Ideal for the production of:

• food preserves, marinades, juices, oils, syrups
• household and technical chemicals
• liquid and semi-liquid cosmetics
• products packed in jars, bottles, and cans
